Bolt Energy 105AH 48 Volt Standard Kit - THIN HIGH OUTPUT GOLF CART LITHIUM BATTERY

Bolt Energy 105AH 48 Volt Standard Kit - THIN HIGH OUTPUT GOLF CART LITHIUM BATTERY

SKU : BE10551T STAN-K

Regular price $2,395.00
$2,395.00 Regular price $3,493.75 Sale price
(31% Off)
On Sale Sold out
Ships in 1-2 Days

Voted Best Lithium Battery in Warranty, Power, and Overall by our team of experts.

You Might Need These

12v Converter(+ $80.10) Required if you don't already have
2 Gauge Cables(+ $79.00) Recommended if you don't have
Fuse Box Holder(+ $39.00) Recommended for multiple 12v accessories
48V for 400+Amp(+ $99.00) Recommended for older carts

Add to Cart

  • #1 in Product Expertise
  • Best Price Guaranteed
  • Fast Shipping
View full details
  • Description
  • Resources

Bolt Energy Batteries are compatible with these golf cart brands: Advanced EV, Bad Boy Buggy, Bintelli, Club Car DS, Club Car Precedent, Coleman, EZGO TXT, EZGO RXV, Elite, EPIC, Evolution, GEM Cars, ICON, Kandi, Madjax X-series, Navitas Storm, Nivel X-series, Titan, Tomberlin, Trojan EV, Vivid, Yamaha. Bolt Energy USA is compatible with many other carts and electric EV vehicles. Please contact us for more information.

The 51V 105Ah “THIN” was developed to be the easiest golf car battery (in certain models) to install in the marketplace.  Golf Cars with the traditional “E-Z-GO” 22-inch-wide battery tray system, which many competitor vehicles have mimicked, accept this battery without the need for mounting brackets. Drill 4 holes into the tray, bolt, and your battery is mounted. This saves significant installation labor time. Although the shape of this battery will prevent use in ALL vehicles, it will still work in 90% of applications. Internally, it is built exactly the same as the MINI with the only difference being the dimensions. Designed for use in all 48-volt power trains. Ranges, depending on how extreme the car is modified and how the car is loaded and driven, range from 20 to 50 miles.


Features

  • 51V-105AH BATTERY
  • Bluetooth receiver
  • SOC “state of charge meter”
  • Owners manual “SIMPLE installation instructions”
  • 6- 3/8 battery ring terminal connectors
  • 10-10″ tie straps
  • Bolt Energy USA sticker/s
  • Waterproof high speed charger
  • Mounting brackets, Nutts & bolts



MECHANICAL SPECIFICATIONS

  • Dimensions (L x W x H): 20″ x 8.43″ x 10.65″
  • Weight: 105lbs (47.63kg)
  • Terminal Type: M8*1.5*25mm
  • Cell Configuration: 1P16S
  • Case Material: Powder Coated Steel
  • Enclosure Protection: Designed with IP66 Stardard
  • Cell Type – Chemistry: Prismatic- LiFePO4


DISCHARGE SPECIFICATIONS

  • Maximum Continuous Discharge Current: 250A
  • Peak Discharge Current: 520A ± 15.6A (30S)
  • BMS Discharge Current Cut-Off:
    • 260 A ± A7.8A (50S)
    • 520A ± 15.6A (30S)
  • BMS Discharge Voltage Cut-Off: 40V
  • Recommended Low Voltage Disconnect: 48.0V
  • BMS Reconnect Voltage: 41.6V
  • Discharge Temperature: -4 to 149°F (-20 to 65°C)


ELECTRICAL SPECIFICATION

  • Nominal Voltage: 51.2V
  • Working Voltage: 43.2 – 58.4V
  • Recommended Voltage: 48.0V – 57.0V
  • Nominal Capacity: 105Ah
  • Energy: 5,376Wh
  • Capacity @ 25A: 252 min
  • Efficiency: 0.99
  • Self Discharge: <3% per Month


CHARGE SPECIFICATIONS

  • Recommended Charge Current: 5 – 52A
  • Maximum Input Current: 350A
  • Charge Current Cut-Off: 375A
  • BMS Charge Voltage Cut-Off: 58.5V
  • Reconnect Voltage: <58.5V
  • Charging Temp. Range: 34°F to 140°F (0-60°C)


COMMUNICATION

  • Bluetooth: Bluetooth receiver

Date Sheet Click Here

INSTALLATION VIDEOS

Bolt Energy USA - THIN 48v 105ah | Lithium Golf Cart Battery Installation Video

Downloads

Date Sheet
