Bolt Energy 105AH 36 Volt Standard Kit - MINI HIGH OUTPUT GOLF CART LITHIUM BATTERY
Product Images & Videos

    • Bolt

    Bolt Energy 105AH 36 Volt Standard Kit - MINI HIGH OUTPUT GOLF CART LITHIUM BATTERY

    Bolt Energy 105AH 36 Volt Standard Kit - MINI HIGH OUTPUT GOLF CART LITHIUM BATTERY

    SKU : BE10538C STAN-K

    $1,995.00
    $1,995.00 $2,993.75
    (33% Off)
    On Sale Sold out
    Ships in 1-2 days

    Voted Best Lithium Battery in Warranty, Power, and Overall by our team of experts.

    Back To Product Page

    • #1 in Product Expertise
    • Best Price Guaranteed
    • Fast Shipping
    View full details
    • Description
    • Resources

    Bolt Energy 105AH 36 Volt Standard Kit - "MINI" HIGH OUTPUT GOLF CART LITHIUM BATTERY

    Bolt Energy Batteries are compatible with these golf cart brands: Advanced EV, Bad Boy Buggy, Bintelli, Club Car DS, Club Car Precedent, Coleman, EZGO TXT, EZGO RXV, Elite, EPIC, Evolution, GEM Cars, ICON, Kandi, Madjax X-series, Navitas Storm, Nivel X-series, Titan, Tomberlin, Trojan EV, Vivid, Yamaha. Bolt Energy USA is compatible with many other carts and electric EV vehicles. Please contact us for more information.

    As the name suggests, the 38-volt 105Ah “CLASSIC” was developed for customers who just can’t let go of their vintage golf car. The 36-volt electrical system, for the most part, has been discontinued as 48- and 72-volt systems are much more efficient. Ranges, depending on how extreme the car is modified and how the car is loaded and driven, range from 15 to 35 miles.

    Features:

    • 38V-105AH BATTERY
    • Bluetooth receiver
    • SOC “state of charge meter”
    • Owners manual “SIMPLE installation instructions”
    • 6- 3/8 battery ring terminal connectors
    • 10-10″ tie straps
    • Bolt Energy USA sticker/s
    • Waterproof high speed charger
    • Mounting brackets, Nutts & bolts

    MECHANICAL SPECIFICATIONS

    • Dimensions (L x W x H): 11.14″ x 10.58″ x 10.67″
    • Weight: 77.27lbs (35.05kg)
    • Terminal Type: M8*1.5*25mm
    • Cell Configuration: 1P16S
    • Case Material: Powder Coated Steel
    • Enclosure Protection: Designed with IP66 Stardard
    • Cell Type – Chemistry: Prismatic- LiFePO4

    DISCHARGE SPECIFICATIONS

    • Maximum Continuous Discharge Current: 250A
    • Peak Discharge Current: 520A ± 15.6A (30S)
    • BMS Discharge Current Cut-Off:
      • 260 A ± A7.8A (50S)
      • 520A ± 15.6A (30S)
    • BMS Discharge Voltage Cut-Off: 30V
    • Recommended Low Voltage Disconnect: 36.0V
    • BMS Reconnect Voltage: 31.2V
    • Discharge Temperature: -4 to 149°F (-20 to 65°C)

    ELECTRICAL SPECIFICATION

    • Nominal Voltage: 38.4V
    • Working Voltage: 32.4 – 43.8V
    • Recommended Voltage: 36.0V – 42.6V
    • Nominal Capacity: 105Ah
    • Energy: 4.032KWh
    • Capacity @ 25A: 252 min
    • Efficiency: 0.99
    • Self Discharge: <3% per Month

    CHARGE SPECIFICATIONS

    • Recommended Charge Current: 5 – 52A
    • Maximum Input Current: 350A
    • Charge Current Cut-Off: 375A
    • BMS Charge Voltage Cut-Off: 43.8V
    • Reconnect Voltage: <43.8V
    • Charging Temp. Range: 34°F to 140°F (0-60°C)

    COMMUNICATION

    • Bluetooth: Bluetooth receiver
    • CAN: CAN port for testing battery

    For Data Sheet Click Here

    Downloads

    Data Sheet
