Bolt Energy 105AH 72 Volt Standard Kit - POWER HIGH OUTPUT GOLF CART LITHIUM BATTERY
Product Images & Videos
Bolt
Bolt Energy 105AH 72 Volt Standard Kit - POWER HIGH OUTPUT GOLF CART LITHIUM BATTERY
Bolt Energy 105AH 72 Volt Standard Kit - POWER HIGH OUTPUT GOLF CART LITHIUM BATTERY
SKU : BE10572P STAN-K
Regular price
$3,295.00
$3,295.00
Regular price
$4,743.75
Sale price
Unit price
per
On Sale
Sold out
Ships in 1-2 days
-
#1 in Product Expertise
-
Best Price Guaranteed
-
Fast Shipping
- Description
- Resources
Bolt Energy 105AH 72 Volt Standard Kit - "POWER" HIGH OUTPUT GOLF CART LITHIUM BATTERY
The 72V 105Ah “POWER” was developed for several reasons. First, extreme applications where customers increase the power (voltage) on demand needed due to modifications such as high-speed controllers and AC motors must upgrade to this battery. Second, 72-volt systems are much more efficient than 36- and 48-volt systems delivering almost as much wattage as the 51V 160Ah “BIG”. In other words, ranges you see out of the “BIG” AND “POWER” batteries are almost equal even though the Ah rating is different. Some OEM golf car manufacturers are moving to 72-volt systems and Bolt Energy is ready for that market shift. Please be aware this battery will not fit in every golf car due to size! Review the spec sheet or give us a call to ensure it will fit in your vehicle before purchase.
Features:
- 72V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 20.08″ x 10.75″ x 10.39″
- Weight: 137.26lbs (62.26kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P23S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
- BMS Discharge Current Cut-Off:
- 260 A ± A7.8A (50S)
- 520A ± 15.6A (30S)
- BMS Discharge Voltage Cut-Off: 57.5V
- Recommended Low Voltage Disconnect: 69.0V
- BMS Reconnect Voltage: 60.0V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 73.6V
- Working Voltage: 62 – 83.95V
- Recommended Voltage: 69V – 81.93V
- Nominal Capacity: 105Ah
- Energy: 7,728Wh
- Capacity @ 25A: 420 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 84V
- Reconnect Voltage: <84V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
Downloads
Data Sheet
Ask an Expert
Buy with confidence. Contact our experts today.
